Entry Level Horse Arena Geotextile Package - Woven Base & Non Woven Top Layer

This entry level horse arena geotextile package is designed for private and light use riding arenas. It provides a proven two layer membrane system, combining a woven geotextile base layer with a non woven fleece top layer, plus joining tape for standard overlap installation.

The woven geotextile is installed above the drainage layer and below the aggregate. Its role is separation and stabilisation, preventing the sub base and drainage stone from mixing while maintaining ground structure over time. As this layer sits beneath the aggregate, it is not subject to direct loading from horses.

The non woven geotextile is installed above the aggregate and directly beneath the riding surface. It provides filtration and separation, keeping fine surface materials such as sand, fibre or waxed blends out of the stone layer while allowing water to drain freely through the arena build up.

This package is intended for domestic and light use manèges only. It is suitable for sand, fibre and waxed surfaces, including installations using grid systems, provided the tread layer depth is sufficient. If there is any risk of horses making contact with the membrane, either the tread layer depth must be increased or a heavier non woven grade should be specified.

What’s included by arena size

20m x 40m Horse Arena Package

• 900m² non woven geotextile membrane, 100gsm (2 rolls of 4.5m x 100m)
• 900m² woven geotextile membrane (2 rolls of 4.5m x 100m)
• 300m single sided geotextile cloth tape (6 rolls of 100mm x 50m)


30m x 40m Horse Arena Package

• 1350m² non woven geotextile membrane, 100gsm (3 rolls of 4.5m x 100m)
• 1350m² woven geotextile membrane (3 rolls of 4.5m x 100m)
• 450m single sided geotextile cloth tape (9 rolls of 100mm x 50m)


20m x 60m Horse Arena Package

• 1350m² non woven geotextile membrane, 100gsm (3 rolls of 4.5m x 100m)
• 1350m² woven geotextile membrane (3 rolls of 4.5m x 100m)
• 450m single sided geotextile cloth tape (9 rolls of 100mm x 50m)


Each package includes allowance for standard overlaps and a practical quantity of joining tape based on typical installation methods. Membranes are joined using overlap and tape rather than glue or heat sealing, keeping installation straightforward and reliable on site.

Standard arena sizes are available as product variations. Bespoke arena sizes can be supplied on request. Contact us with your arena dimensions and we will configure a custom package to suit.

• Entry level geotextile package for domestic horse arenas
• Two layer system using woven and non woven membranes
• Provides separation, filtration and ground stability
• Suitable for sand, fibre and waxed riding surfaces
• Includes joining tape for overlap installation
• Size options available with bespoke packages on request

The woven and non woven membranes are manufactured from polypropylene. The woven fabric provides tensile strength and stabilisation at base level, while the non woven fleece offers filtration and separation beneath the riding surface.

Non Woven Geotextile (Top Layer)

• Fabric type: Non woven geotextile membrane
• Weight: 100gsm
• Roll size: 4.5m x 100m


Woven Geotextile (Base Layer)

• Fabric type: Woven geotextile membrane
• Weight: approx. 78gsm
• Roll size: 4.5m x 100m


Joining Tape

• Type: Single sided geotextile cloth tape
• Roll size: 100mm x 50m
